ESD (Electro-Static Dissipative) Floors/Clean Rooms

By dciflooringUncategorized

Uncontrolled static discharge can disrupt the function of your business, costing you both time and money. Dynamic Coatings offers three Electro-Static Dissipative floor systems provided by Dur-A-Flex, each designed to dissipate the static charge caused by the movement of people, equipment, and high-speed manufacturing and assembly equipment. These systems, Dur-A-Gard ESD, Armor-Stat ESD and Cryl-A-Stat ESD have the ability to ground out static charges and prevent static events from occurring. Dur-A-Flex’s safe and dependable ESD flooring systems have been designed with you and your facility needs in mind, preventing static charges from interrupting your flow of production and on-time delivery of products to your customers. Each system provides you with a durable,seamless, non-porous and easy to clean floor designed to meet your most demanding electronics manufacturing and automated assembly requirements.



Typical uses:

  • Clean Rooms
  • Automated Assembly Areas
  • Computer Control Rooms
  • Electronic Assembly Areas
  • Storage Areas
  • Electronic Manufacturing Plants
  • Packaging Plants
  • AGV Warehouses



Dur-A-Gard ESD

An epoxy-based ESD system offering low odor with a smooth finish. Good abrasion and chemical resistance in a two component system.



Armor-Stat ESD

An epoxy-urethane ESD system offering superior abrasion and chemical resistance makes it one of the longest-wearing ESD floor systems available in the industry. The three-step system offers our highest static protection from primer through urethane topcoat. Excellent UV resistance ensures consistent color throughout the life of the floor.
Cryl-A-Stat ESD-401
A methyl methacrylate-based acrylic (MMA), this ESD floor sealer is used over standard MMA floor systems offering a quick, one-hour cure for fast installations. Excellent UV resistance provides consistent color stability.

DUR-A-GARD ESD

DUR-A-GARD ESD is a 2-component, pigmented 100% solids static dissipative coating. This coating provides a static dissipative ( W/Square) surface with a high gloss finish. DUR-A-GARD ESD provides an average of 14v Body Voltage Generation when utilizing dissipative footwear. Resistance readings are consistent for the life of the floor and are independent of ambient humidity. DUR-A-GARD ESD protects new and existing concrete floors from many chemicals and was designed for ultimate cleanability. The system is designed for areas where dirt or dust cannot be tolerated while providing static dissipation to protect against electrostatic discharge.

Benefits:

  • Static Dissipative * Durable
  • Easy to Clean
  • 14v Avg. BVG
  • Stain Resistant
  • Dissipates 5000 Volt charge to Zero in 0.01 seconds



Typical Uses:

  • Pharmaceutical Facilities
  • Clean Rooms
  • Packaging Lines
  • Processing Areas
  • Laboratories
  • Plastic Manufacturing
  • Electronics Assembly



Technical Information

Color                                                                      Arctic Grey, Beige, Medium Grey, Slate Grey, Smoke Blue, and Tile Red
Cure Time, Touch Dry at 70° F                        8-10 hours
Cured Film Thickness                                        16 mils
Toxicity                                                                  Non-Toxic, USDA approved
Flammability                                                        Self-Extinguishing

ARMOR STAT ESD

ARMOR STAT ESD is an epoxy/urethane, pigmented, static dissipative floor coating system. This system provides a static dissipative floor from primer though the satin finish topcoat. ARMOR STAT ESD provides an average of 5v Body Voltage Generation when utilizing dissipative footwear. Resistance readings are consistent for the life of the floor and are independent of ambient humidity. ARMOR STAT ESD protects new and existing concrete floors from many chemicals and designed to provide the ultimate in wear resistance, chemical resistance and cleanability. The system is designed for areas where dirt or dust cannot be tolerated while providing static dissipation to protect against electrostatic discharge.

Benefits

  • Static Dissipative
  • UV Stable
  • Dissipates 5000
  • Volt charge to
  • Zero in 0.01 seconds
  • VOC Compliant
  • Superior Wear Resistance
  • Excellent Stain Resistance
  • Easy to Clean
  • 5v Avg. BVG with dissipative footwear



Typical Uses

  • Pharmaceutical Facilities
  • Processing Areas
  • Clean Rooms
  • Packaging Lines
  • Laboratories
  • Plastic Manufacturing
  • AGV Warehouses
  • Electronics Assembly



Technical Information

Color                                                                                                  Arctic Grey, Beige, Medium Grey, Slate Grey, and Smoke Blue
Cure Time, Touch Dry at 70° F (per component)                    8 – 10 Hours
Cured Film Thickness (nominal)                                                28 mils
Toxicity                                                                                             Non-Toxic, USDA approved
Flammability                                                                                   Self-Extinguishing

CRYL-A-STAT ESD-401

CRYL-A-STAT ESD-401 is a 100% solids conductive sealer methyl methacrylate (MMA) based, acrylic reactive resin. It is formulated to form a monolithic bond with other DUR-A-FLEX systems and to be UV resistant.

Benefits

  • VOC compliant, < 100 g/L
  • Fast cure, full strength in less than one hour
  • UV resistant
  • Seamless, no cold joints, always bonds to itself
  • Prevents electrical charge accumulation



Typical Uses

CRYL-A-STAT ESD-401 is intended to be used in
areas where a conductive or antistatic coating is
needed.

Technical Information

CRYL-A-STAT ESD-401 is part of a wide range of special repair and wearing materials supplied by DUR-A-FLEX. If you require further information on this or any other of our products please contact our Technical Department.
